pr4788050

Uponor PP-RCT Saddle, 8" x 1/2", for Outlet Fusion

Part no.PR4788050
StatusActive

Part information and details

Codes

CodesCMC|IMC|UMC

Dimensions

A [frac]37/64 inch
A [inch]0.571 inch
B [frac]13/64 inch
B [inch]0.197 inch
C [frac]25/32 inch
C [inch]0.787 inch
D [frac]1 45/64 inch
D [inch]1.699 inch
E [frac]1 3/64 inch
E [inch]1.046 inch
F [frac]7 29/32 inch
F [inch]7.904 inch
Weight per UOM [lbs/UOM]0.02 lbs/uom

Listings

ListingsICC-ES-PMG 1106|IAPMO-R&T 8358|QAI P321-5|IAPMO K-12775

Standards

StandardsNSF-61|ASTM E84|NSF-14|ASTM F2389|CSA B137.11

Technical Data

End Size 1 [inch|mm]8"
End Size 2 [inch|mm]1/2"
End Type 1Saddle
End Type 2Socket
Material groupPP-RCT
