Uponor PP-RCT Transition Saddle, 10" x 1", Female NPT, for Outlet Fusion

Part no.PR47910010
StatusActive

Part information and details

Codes

CodesCMC|IMC|UMC

Dimensions

A [frac]1 5/32 inch
A [inch]1.151 inch
B [frac]1 1/2 inch
B [inch]1.496 inch
C [frac]21/32 inch
C [inch]0.661 inch
D [frac]2 23/64 inch
D [inch]2.362 inch
E [frac]2 41/64 inch
E [inch]2.647 inch
F [frac]1 3/16 inch
F [inch]1.181 inch
G [frac]53/64 inch
G [inch]0.835 inch
H [frac]5/8 inch
H [inch]0.63 inch
I [frac]1 17/64 inch
I [inch]1.26 inch
J [frac]9 27/32 inch
J [inch]9.843 inch
Equivalent length through [ft]1.7 ft
Weight per UOM [lbs/UOM]0.44 lbs/uom

Listings

ListingsICC-ES-PMG 1106|IAPMO-R&T 8358|QAI P321-5|IAPMO K-12775

Standards

StandardsNSF-61|ASTM E84|NSF-14|ASTM F2389|CSA B137.11

Technical Data

End Size 1 [inch|mm]10"
End Size 2 [inch|mm]1"
End Type 1Saddle
End Type 2FNPT
Material groupPP-RCT
Prop 65 label required?Yes
