1" PEX-a Pipe Support, 9-ft. length
Número de piezaF7041000
EstadoActivo
Encuentre un distribuidor
La disponibilidad de productos específicos varía según el distribuidor.
Información y detalles de la pieza
Codes
| Codes | IMC|UMC |
|---|
Dimensions
| A [frac] | 108 inch |
|---|---|
| A [inch] | 108 inch |
| B [frac] | 1 5/32 inch |
| B [inch] | 1.163 inch |
| C [frac] | 45/64 inch |
| C [inch] | 0.698 inch |
| Weight per UOM [lbs/UOM] | 1.91 lbs/uom |
Listings
| Listings | QAI P321 (up to 3") |
|---|
Standards
| Standards | ASTM E84 |
|---|
Technical Data
| Material group | Metal |
|---|---|
| Submittal Subcomponent Material | Commercial-grade (Type B) galvanized steel |
