PR47810030

Uponor PP-RCT Saddle, 10" x 3", for Outlet Fusion

Part no.PR47810030
StatusActive

Part information and details

Codes

CodesCMC|IMC|UMC

Dimensions

A [frac]1 3/8 inch
A [inch]1.378 inch
B [frac]7/16 inch
B [inch]0.433 inch
C [frac]3 9/16 inch
C [inch]3.559 inch
D [frac]3 3/8 inch
D [inch]3.374 inch
E [frac]4 23/64 inch
E [inch]4.354 inch
F [frac]9 7/8 inch
F [inch]9.874 inch
Equivalent length through [ft]3 ft

Listings

ListingsICC-ES-PMG 1106|IAPMO-R&T 8358|QAI P321-5|IAPMO K-12775

Standards

StandardsASTM E84|NSF-14|ASTM F2389|CSA B137.11

Technical Data

End Size 1 [inch|mm]10"
End Size 2 [inch|mm]3"
End Type 1Saddle
End Type 2Socket
Operating Pressure 1 [PSI]270 psi
Operating Pressure 2 [PSI]176 psi
Operating Pressure 3 [PSI]120 psi
Operating Temperature 1 [°F]73 °f
Operating Temperature 2 [°F]120 °f
Operating Temperature 3 [°F]180 °f
Material groupPP-RCT
