PR4786013

Uponor PP-RCT Saddle, 6" x 1 1/4", for Outlet Fusion

Part no.PR4786013
StatusActive

Part information and details

Codes

CodesCMC|IMC|UMC

Dimensions

A [frac]13/16 inch
A [inch]0.807 inch
B [frac]17/64 inch
B [inch]0.264 inch
C [frac]1 37/64 inch
C [inch]1.575 inch
D [frac]1 29/32 inch
D [inch]1.906 inch
E [frac]2 3/64 inch
E [inch]2.047 inch
F [frac]6 19/64 inch
F [inch]6.299 inch
Equivalent length through [ft]1.3 ft

Listings

ListingsICC-ES-PMG 1106|IAPMO-R&T 8358|QAI P321-5|IAPMO K-12775

Standards

StandardsASTM E84|NSF-14|ASTM F2389|CSA B137.11

Technical Data

End Size 1 [inch|mm]6"
End Size 2 [inch|mm]1-1/4"
End Type 1Saddle
End Type 2Socket
Operating Pressure 1 [PSI]270 psi
Operating Pressure 2 [PSI]176 psi
Operating Pressure 3 [PSI]120 psi
Operating Temperature 1 [°F]73 °f
Operating Temperature 2 [°F]120 °f
Operating Temperature 3 [°F]180 °f
Material groupPP-RCT
