PR4512075

Uponor ProPEX LF Brass Saddle Adapter, 2" / 3/4" PP-RCT x 3/4" PEX, for Outlet Fusion

Part no.PR4512075
StatusActive

Part information and details

Codes

CodesCMC|IMC|UMC

Dimensions

A [frac]1 11/64 inch
A [inch]1.177 inch
B [frac]63/64 inch
B [inch]0.984 inch
C [frac]2 31/64 inch
C [inch]2.48 inch
D [frac]1 43/64 inch
D [inch]1.665 inch
E [frac]2 3/4 inch
E [inch]2.748 inch
Equivalent length through [ft]5.2 ft

Listings

ListingsICC-ES-PMG 1106|IAPMO-R&T 8358

Standards

StandardsASTM F1960|NSF-14|ASTM F2389|CSA B137.11

Technical Data

End Size 1 [inch|mm]2"
End Size 2 [inch|mm]3/4"
End Type 1Saddle
End Type 2ProPEX
Operating Pressure 1 [PSI]270 psi
Operating Pressure 2 [PSI]176 psi
Operating Pressure 3 [PSI]120 psi
Operating Temperature 1 [°F]73 °f
Operating Temperature 2 [°F]120 °f
Operating Temperature 3 [°F]180 °f
Material groupPP-RCT
Prop 65 label required?No
