2D Customer Drawings
54 B0000086816
IQ STORM WATER REDUCER ID300/ID250 SPIGOT
Item details
Technical data
| Item UOM | Piece |
|---|---|
| Outer Diameter_do | 339 mm |
| Z-measurement d | 300 mm |
| Z-measurement d1 | 250 mm |
| Z-measurement M | 170 mm |
| z1 | 15 mm |
