Uponor Smatrix Base wallframe style T-149 A-14x black

- Up to 4 controllers in one system
- Operating voltage: 230V
- Autobalancing optimises energy user and comfort
- Supports up to 6 room thermostats and 8 24V
actuators per controller
- Pump and boiler relays
- Valve and pump exercise
- Relative humidity control
- Different wiring options (daisy-chain / star)
- 4-wire Bus installation
- Communication protocol: RS485 serial bus
- Max. power input per actuator: 24VAC / 0.2A (0.4A peak)

Smatrix Base Pulse:
- Local access (Wi-Fi) or remote access (internet connection
required) via Uponor Smatrix Pulse App (with R-208)
- Temporary wi-fi access point for direct access
(if local wi-fi is not available) - (with R-208)
- Smart home ecosystem integration (Amazon Alexa,
Google Home) - (with R-208)
- Multi-home control - (with R-208)
- Third-party access for remote support
(user allowance required) - (with R-208)
- History trend analysis via Uponor Smatrix Pulse app
(with R-208)
- Timer programming (with R-208)
- Comfort settings (with R-208)
- Supply diagnostics (with R-208)

- Wired room temperature control for radiant heating
and cooling
- Set point range: +5°C - +35°C

- CE / EAC
