Fabricated reducers
Item details
1056659 / - / -
PRESSURE REDUCER 75-63 PN10 SDR17 PE100 LONG
1055685 / - / -
PRESSURE REDUCER 110-63 PN10 SDR17 PE100 LONG
1056656 / - / -
PRESSURE REDUCER 110-75 PN10 SDR17 PE100 LONG
1056657 / - / -
PRESSURE REDUCER 140-110 PN10 SDR17 PE100 LONG
1033657 / - / -
PRESSURE REDUCER 160-110 PN10 SDR17 PE100 LONG
1052115 / - / -
PRESSURE REDUCER 160-125 PN10 SDR17 PE100 LONG
1052116 / - / -
PRESSURE REDUCER 160-140 PN10 SDR17 PE100 LONG
1052114 / - / -
PRESSURE REDUCER 160-90 PN10 SDR17 PE100 LONG
1056660 / - / -
PRESSURE REDUCER 180-160 PN10 SDR17 PE100 LONG
1033658 / - / -
PRESSURE REDUCER 200-160 PN10 SDR17 PE100 LONG
1052117 / - / -
PRESSURE REDUCER 225-160 PN10 SDR17 PE100 LONG
1056658 / - / -
PRESSURE REDUCER 250-180 PN10 SDR17 PE100 LONG
1052119 / - / -
PRESSURE REDUCER 250-200 PN10 SDR17 PE100 LONG
1056661 / - / -
PRESSURE REDUCER 250-225 PN10 SDR17 PE100 LONG
1056663 / - / -
PRESSURE REDUCER 315-250 PN10 SDR17 PE100 LONG
1068446 / - / -
PRESSURE REDUCER 315-280 PN10 SDR17 PE100 SEGMENT WELDED
1068448 / - / -
PRESSURE REDUCER 355-280 PN10 SDR17 PE100 SEGMENT WELDED
1068449 / - / -
PRESSURE REDUCER 355-315 PN10 SDR17 PE100 SEGMENT WELDED
1068451 / - / -
PRESSURE REDUCER 400-315 PN10 SDR17 PE100 SEGMENT WELDED
1068452 / - / -
PRESSURE REDUCER 400-355 PN10 SDR17 PE100 SEGMENT WELDED
1068454 / - / -
PRESSURE REDUCER 450-355 PN10 SDR17 PE100 SEGMENT WELDED
1068455 / - / -
PRESSURE REDUCER 450-400 PN10 SDR17 PE100 SEGMENT WELDED
1068456 / - / -
PRESSURE REDUCER 500-355 PN10 SDR17 PE100 SEGMENT WELDED
1068457 / - / -
PRESSURE REDUCER 500-400 PN10 SDR17 PE100 SEGMENT WELDED
1068458 / - / -
PRESSURE REDUCER 500-450 PN10 SDR17 PE100 SEGMENT WELDED
1068461 / - / -
PRESSURE REDUCER 560-500 PN10 SDR17 PE100 SEGMENT WELDED
1068463 / - / -
PRESSURE REDUCER 630-500 PN10 SDR17 PE100 SEGMENT WELDED
1052185 / - / -
PRESSURE REDUCER 110-63 PN16 SDR11 PE100 LONG
1052187 / - / -
PRESSURE REDUCER 125-110 PN16 SDR11 PE100 LONG
1052190 / - / -
PRESSURE REDUCER 160-125 PN16 SDR11 PE100 LONG
1052189 / - / -
PRESSURE REDUCER 160-90 PN16 SDR11 PE100 LONG
1055696 / - / -
PRESSURE REDUCER 250-200 PN16 SDR11 PE100 LONG
Documents
Technical manuals
2D Customer Drawings
74 B0000088088
Mounting dimensions Pressure reducer PN16 SDR11 long
2D Customer Drawings
74 B0000088086
Mounting dimensions Pressure reducer PN16 SDR11 long
